Compact with excellent cost performance, this series also saves time with simple design software!
GOP-LT35A&43A
DEVICE
The LT series, with its excellent cost performance, is a new addition to our Graphic Operation Panel (GOP) product range.
The LT series is a range of next-generation standard display panels with diverse expressive capabilities. These highly versatile products have compact casing, and provide intuitive HMI for FA/OA machines, measuring equipment, medical equipment and food industry machinery.
GOP−LT35A
| Liquid Crystal | 3.5 Inch High Luminance Wide-Viewing Angle TFT LCD Display (LED BL) |
| LCD Display Area | 53.64 x 71.52 mm |
| Pixel Count (W x H) | 240 x 320 pixels |
| No. Colors Displayed | 32,768 colors |
| External Interface | - UART1 (for host communication) Bit Length Settings：8 bit Parity：None Stop Bit：1bit Baud Rate：38400/115200 bps - UART2 (Use: Simple debugging console) Bit Length Settings: 8 bit Parity: None Stop Bit: 1 bit Baud rate: 115200 bps - SPI (Slave) Frequency: Max 2MHz |
| Power Rating | DC 5V ±10% |
| Power Consumption | 5W Max (1.5W) |
| Operating Temperature | 0 to +50℃/10% - 85% RH(however, avoid condensation) |
| Dimensions | 78 x 87 x 24 mm |
| Individual Unit Weight | Approx. 140g |
| RoHS Directive | Compatible |
GOP−LT43A
| Liquid Crystal | 4.3 Inch High Luminance/Wide-Viewing Angle TFT LCD (LED BL) |
| LCD Display Area | 95.04 x 53.86 mm |
| Pixel Count (WX H) | 480 x 272 pixel |
| No. Colors Displayed | 32,768 colors |
| External Interface | - UARTI (For host communication use) Bit Length Settings：8 bit Parity：None Stop Bit：1 bit Baud Rate：38400 / 115200 bps - UART2 (Use: Simple debugging console) Bit Length Settings: 8 bit Parity：None Stop Bit: 1 bit Baud Rate: 115200 bps - SPI (Slave) Frequency: Max 2MHz |
| Power Rating | DC 5V±10% |
| Power Consumption | 5W Max (1.7W) |
| Operating Temperature | 0 to +50℃/10% - 85% RH (However, avoid condensation) |
| Dimensions | 120 x 67.2 x 20 mm |
| Individual Unit Weight | Approx. 140g |
| RoHS Directive | Compatible |
Specifications
- ■ High Resolution Color LCD Touch Panels
- These color LCD touch panels have resolutions of WGVGA (480 x 272) for 4.3 inch displays and VGA (680 x 480) for 5.6 inch displays, and have highly detailed expressive capabilities.
- ■ Compact Designs with Open Frame Structures Ideal for Installation
- The panels are housed in compact cases only very slightly larger than the LCD screen size, include USB and other interfaces, and are perfect for installing into the latest machine systems.
- ■ Simple Screen Editing
- Screen data can be easily rewritten either during manufacturing or in the field, using USB memory drives.
- ■ Versatile Screen Designs for a Range of Applications
- ● The panels include versatile screen design options for a range of applications, with an inbuilt specialized screen design tool (TP-Designer LT) for quick, simple screen design editing.
- ● Layers: Up to 3 layers are available on-screen (including transparency options).
- ■ Specialized Screen Design Software for the LT Series (TP-Designer LT)
- ● Compatible with the GOP-LT series.
- ● Intuitive design capabilities for GUI and functional designs.
- ● Button operation settings can be defined using the "Define operations using command selections" option.
- ● Images can be easily brought in to the system (BMP, JPEG and clipboard images).
- ● Reading/rewriting the internal memory is also possible via connection to a GOP unit.
- *This requires either a conversion module (GOP-USCM) or a USB memory drive.
- ● Screen data can also be rapidly rewritten using SPI.
- * This requires a conversion module (GOP-USCM).
- ● Recommended Operating Environment:
- CPU 1GHz+, Memory 1GB+ Required OS: Windows 7, 8.1, 10 (32/64 bit)
